Electric Booster Pump - EBP^®40 (Part #9040)

A high-performance brushless motor, magnetic-drive pump. Compact and versatile pump for a range of applications.

This high-performance 35 litre per minute, brushless, magnetically driven EBP^® has drawn high acclaim globally for its diversity of applications. These include booster for car heater and LPG systems, solar and marine applications, water-cooled motorcycle, go-kart engines, turbo air/water intercoolers, caravans, motor homes and domestic irrigation.

The EBP^® is a recirculating pump which is ideal for a ‘closed system’ similar to an automotive cooling system; it is not self priming’. For optimum coolant flow control, use either of Davies, Craig Thermatic Switches (#0400, #0444 or #0500).

The EBP^®40 is offered in both 12 and 24 Volt (Part #9041)

UN ECE Regulation 10 compliant for improved electromagnetic compatibility (EMC) in automotive applications. Approval No: E24*10R06/02*4722*00:

ELECTRIC BOOSTER PUMP SELECTION GUIDE

EBP APPLICATION OPTIONS

1. Circulation Pump for LPG Vehicles – The EBP improves water circulation through the engine block to prevent LPG injector from icing up. Other advantages include a more even engine temperature and better engine cooling.
2. Heater Booster Pump – The EBP increases heater performance during normal vehicle operation and enables continued heater usage when engine is off (but IGNITION is ON).
3. Water Pump for Liquid Cooled Motorcycle Engines - The EBP provides liquid circulation independent of the engine speed to provide cooling at all levels. It may be used with the EWP Digital Controller to replace the existing water pump or used with an override switch to compliment the existing system.
4. Multi-Purpose Pump – The EBP may be used in a number of different applications where flow is required, such as irrigation, camping, solar pumps, go-karts or marine operations.
